Scheduling

Filters host by CPU core numbers with a per-aggregate cpu_allocation_ratio value. If the per-aggregate value is not found, the value falls back to the global setting. If the host is in more than one aggregate and more than one value is found, the minimum value will be used. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “CoreFilter”.

Filters host by disk allocation with a per-aggregate disk_allocation_ratio value. If the per-aggregate value is not found, the value falls back to the global setting. If the host is in more than one aggregate and more than one value is found, the minimum value will be used. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “DiskFilter”.

Matches properties defined in an image's metadata against those of aggregates to determine host matches:

For example, the following aggregate myWinAgg has the Windows operating system as metadata (named 'windows'):

$ nova aggregate-details MyWinAgg
+----+----------+-------------------+------------+---------------+
| Id | Name     | Availability Zone | Hosts      | Metadata      |
+----+----------+-------------------+------------+---------------+
| 1  | MyWinAgg | None              | 'sf-devel' | 'os=windows'  |
+----+----------+-------------------+------------+---------------+

In this example, because the following Win-2012 image has the windows property, it boots on the sf-devel host (all other filters being equal):

$ glance image-show Win-2012
+------------------+--------------------------------------+
| Property         | Value                                |
+------------------+--------------------------------------+
| Property 'os'    | windows                              |
| checksum         | f8a2eeee2dc65b3d9b6e63678955bd83     |
| container_format | ami                                  |
| created_at       | 2013-11-14T13:24:25                  |
| ...

You can configure the AggregateImagePropertiesIsolation filter by using the following options in the nova.conf file:

# Considers only keys matching the given namespace (string).
aggregate_image_properties_isolation_namespace = <None>

# Separator used between the namespace and keys (string).
aggregate_image_properties_isolation_separator = .

Matches properties defined in extra specs for an instance type against admin-defined properties on a host aggregate. Works with specifications that are scoped with aggregate_instance_extra_specs. For backward compatibility, also works with non-scoped specifications; this action is highly discouraged because it conflicts with ComputeCapabilitiesFilter filter when you enable both filters. For information about how to use this filter, see the host aggregates section.

Filters host by disk allocation with a per-aggregate max_io_ops_per_host value. If the per-aggregate value is not found, the value falls back to the global setting. If the host is in more than one aggregate and more than one value is found, the minimum value will be used. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “IoOpsFilter”.

Isolates tenants to specific host aggregates. If a host is in an aggregate that has the filter_tenant_id metadata key, the host creates instances from only that tenant or list of tenants. A host can be in different aggregates. If a host does not belong to an aggregate with the metadata key, the host can create instances from all tenants.

Filters host by number of instances with a per-aggregate max_instances_per_host value. If the per-aggregate value is not found, the value falls back to the global setting. If the host is in more than one aggregate and thus more than one value is found, the minimum value will be used. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “NumInstancesFilter”.

Filters host by RAM allocation of instances with a per-aggregate ram_allocation_ratio value. If the per-aggregate value is not found, the value falls back to the global setting. If the host is in more than one aggregate and thus more than one value is found, the minimum value will be used. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “RamFilter”.

Filters host by per-aggregate instance_type value. For information about how to use this filter, see the section called “Host aggregates and availability zones”. See also the section called “TypeAffinityFilter”.

This is a no-op filter. It does not eliminate any of the available hosts.

Filters hosts by availability zone. You must enable this filter for the scheduler to respect availability zones in requests.

Matches properties defined in extra specs for an instance type against compute capabilities.

If an extra specs key contains a colon (:), anything before the colon is treated as a namespace and anything after the colon is treated as the key to be matched. If a namespace is present and is not capabilities, the filter ignores the namespace. For backward compatibility, also treats the extra specs key as the key to be matched if no namespace is present; this action is highly discouraged because it conflicts with AggregateInstanceExtraSpecsFilter filter when you enable both filters.

Passes all hosts that are operational and enabled.

In general, you should always enable this filter.

Only schedules instances on hosts if sufficient CPU cores are available. If this filter is not set, the scheduler might over-provision a host based on cores. For example, the virtual cores running on an instance may exceed the physical cores.

You can configure this filter to enable a fixed amount of vCPU overcommitment by using the cpu_allocation_ratio configuration option in nova.conf. The default setting is:

cpu_allocation_ratio = 16.0

With this setting, if 8 vCPUs are on a node, the scheduler allows instances up to 128 vCPU to be run on that node.

To disallow vCPU overcommitment set:

cpu_allocation_ratio = 1.0

	Note
	The Compute API always returns the actual number of CPU cores available on a compute node regardless of the value of the cpu_allocation_ratio configuration key. As a result changes to the cpu_allocation_ratio are not reflected via the command line clients or the dashboard. Changes to this configuration key are only taken into account internally in the scheduler.

Filters hosts based on the NUMA topology that was specified for the instance through the use of flavor extra_specsin combination with the image properties, as described in detail in the related nova-spec document: Filter will try to match the exact NUMA cells of the instance to those of the host. It will consider the standard over-subscription limits each cell, and provide limits to the compute host accordingly.

	Note
	If instance has no topology defined, it will be considered for any host. If instance has a topology defined, it will be considered only for NUMA capable hosts.

Schedules the instance on a different host from a set of instances. To take advantage of this filter, the requester must pass a scheduler hint, using different_host as the key and a list of instance UUIDs as the value. This filter is the opposite of the SameHostFilter. Using the nova command-line tool, use the --hint flag. For example:

$ nova boot --image cedef40a-ed67-4d10-800e-17455edce175 --flavor 1 \
  --hint different_host=a0cf03a5-d921-4877-bb5c-86d26cf818e1 \
  --hint different_host=8c19174f-4220-44f0-824a-cd1eeef10287 server-1

With the API, use the os:scheduler_hints key. For example:

{
    "server": {
        "name": "server-1",
        "imageRef": "cedef40a-ed67-4d10-800e-17455edce175",
        "flavorRef": "1"
    },
    "os:scheduler_hints": {
        "different_host": [
            "a0cf03a5-d921-4877-bb5c-86d26cf818e1",
            "8c19174f-4220-44f0-824a-cd1eeef10287"
        ]
    }
}

Only schedules instances on hosts if there is sufficient disk space available for root and ephemeral storage.

You can configure this filter to enable a fixed amount of disk overcommitment by using the disk_allocation_ratio configuration option in the nova.conf configuration file. The default setting disables the possibility of the overcommitment and allows launching a VM only if there is a sufficient amount of disk space available on a host:

disk_allocation_ratio = 1.0

DiskFilter always considers the value of the disk_available_least property and not the one of the free_disk_gb property of a hypervisor's statistics:

$ nova hypervisor-stats
+----------------------+-------+
| Property             | Value |
+----------------------+-------+
| count                |  1    |
| current_workload     |  0    |
| disk_available_least |  29   |
| free_disk_gb         |  35   |
| free_ram_mb          |  3441 |
| local_gb             |  35   |
| local_gb_used        |  0    |
| memory_mb            |  3953 |
| memory_mb_used       |  512  |
| running_vms          |  0    |
| vcpus                |  2    |
| vcpus_used           |  0    |
+----------------------+-------+

As it can be viewed from the command output above, the amount of the available disk space can be less than the amount of the free disk space. It happens because the disk_available_least property accounts for the virtual size rather than the actual size of images. If you use an image format that is sparse or copy on write so that each virtual instance does not require a 1:1 allocation of a virtual disk to a physical storage, it may be useful to allow the overcommitment of disk space.

To enable scheduling instances while overcommitting disk resources on the node, adjust the value of the disk_allocation_ratio configuration option to greater than 1.0:

disk_allocation_ratio > 1.0

	Note
	If the value is set to >1, we recommend keeping track of the free disk space, as the value approaching 0 may result in the incorrect functioning of instances using it at the moment.

	Note
	This filter is deprecated in favor of ServerGroupAffinityFilter.

The GroupAffinityFilter ensures that an instance is scheduled on to a host from a set of group hosts. To take advantage of this filter, the requester must pass a scheduler hint, using group as the key and an arbitrary name as the value. Using the nova command-line tool, use the --hint flag. For example:

$ nova boot --image IMAGE_ID --flavor 1 --hint group=foo server-1

This filter should not be enabled at the same time as GroupAntiAffinityFilter or neither filter will work properly.

	Note
	This filter is deprecated in favor of ServerGroupAntiAffinityFilter.

The GroupAntiAffinityFilter ensures that each instance in a group is on a different host. To take advantage of this filter, the requester must pass a scheduler hint, using group as the key and an arbitrary name as the value. Using the nova command-line tool, use the --hint flag. For example:

$ nova boot --image IMAGE_ID --flavor 1 --hint group=foo server-1

This filter should not be enabled at the same time as GroupAffinityFilter or neither filter will work properly.

Filters hosts based on properties defined on the instance's image. It passes hosts that can support the specified image properties contained in the instance. Properties include the architecture, hypervisor type, hypervisor version (for Xen hypervisor type only), and virtual machine mode.

For example, an instance might require a host that runs an ARM-based processor, and QEMU as the hypervisor. You can decorate an image with these properties by using:

$ glance image-update img-uuid --property architecture=arm --property hypervisor_type=qemu

The image properties that the filter checks for are:

Allows the admin to define a special (isolated) set of images and a special (isolated) set of hosts, such that the isolated images can only run on the isolated hosts, and the isolated hosts can only run isolated images. The flag restrict_isolated_hosts_to_isolated_images can be used to force isolated hosts to only run isolated images.

The admin must specify the isolated set of images and hosts in the nova.conf file using the isolated_hosts and isolated_images configuration options. For example:

isolated_hosts = server1, server2
isolated_images = 342b492c-128f-4a42-8d3a-c5088cf27d13, ebd267a6-ca86-4d6c-9a0e-bd132d6b7d09

The IoOpsFilter filters hosts by concurrent I/O operations on it. Hosts with too many concurrent I/O operations will be filtered out. The max_io_ops_per_host option specifies the maximum number of I/O intensive instances allowed to run on a host. A host will be ignored by the scheduler if more than max_io_ops_per_host instances in build, resize, snapshot, migrate, rescue or unshelve task states are running on it.

The JsonFilter allows a user to construct a custom filter by passing a scheduler hint in JSON format. The following operators are supported:

The filter supports the following variables:

Using the nova command-line tool, use the --hint flag:

$ nova boot --image 827d564a-e636-4fc4-a376-d36f7ebe1747 \
  --flavor 1 --hint query='[">=","$free_ram_mb",1024]' server1

With the API, use the os:scheduler_hints key:

{
    "server": {
        "name": "server-1",
        "imageRef": "cedef40a-ed67-4d10-800e-17455edce175",
        "flavorRef": "1"
    },
    "os:scheduler_hints": {
        "query": "[>=,$free_ram_mb,1024]"
    }
}

Filters hosts based on metrics weight_setting. Only hosts with the available metrics are passed so that the metrics weigher will not fail due to these hosts.

Hosts that have more instances running than specified by the max_instances_per_host option are filtered out when this filter is in place.

The filter schedules instances on a host if the host has devices that meet the device requests in the extra_specs attribute for the flavor.

Only schedules instances on hosts that have sufficient RAM available. If this filter is not set, the scheduler may over provision a host based on RAM (for example, the RAM allocated by virtual machine instances may exceed the physical RAM).

You can configure this filter to enable a fixed amount of RAM overcommitment by using the ram_allocation_ratio configuration option in nova.conf. The default setting is:

ram_allocation_ratio = 1.5

This setting enables 1.5 GB instances to run on any compute node with 1 GB of free RAM.

Filters out hosts that have already been attempted for scheduling purposes. If the scheduler selects a host to respond to a service request, and the host fails to respond to the request, this filter prevents the scheduler from retrying that host for the service request.

This filter is only useful if the scheduler_max_attempts configuration option is set to a value greater than zero.

Schedules the instance on the same host as another instance in a set of instances. To take advantage of this filter, the requester must pass a scheduler hint, using same_host as the key and a list of instance UUIDs as the value. This filter is the opposite of the DifferentHostFilter. Using the nova command-line tool, use the --hint flag:

$ nova boot --image cedef40a-ed67-4d10-800e-17455edce175 --flavor 1 \
  --hint same_host=a0cf03a5-d921-4877-bb5c-86d26cf818e1 \
  --hint same_host=8c19174f-4220-44f0-824a-cd1eeef10287 server-1

With the API, use the os:scheduler_hints key:

{
    "server": {
        "name": "server-1",
        "imageRef": "cedef40a-ed67-4d10-800e-17455edce175",
        "flavorRef": "1"
    },
    "os:scheduler_hints": {
        "same_host": [
            "a0cf03a5-d921-4877-bb5c-86d26cf818e1",
            "8c19174f-4220-44f0-824a-cd1eeef10287"
        ]
    }
}

The ServerGroupAffinityFilter ensures that an instance is scheduled on to a host from a set of group hosts. To take advantage of this filter, the requester must create a server group with an affinity policy, and pass a scheduler hint, using group as the key and the server group UUID as the value. Using the nova command-line tool, use the --hint flag. For example:

$ nova server-group-create --policy affinity group-1
$ nova boot --image IMAGE_ID --flavor 1 --hint group=SERVER_GROUP_UUID server-1

The ServerGroupAntiAffinityFilter ensures that each instance in a group is on a different host. To take advantage of this filter, the requester must create a server group with an anti-affinity policy, and pass a scheduler hint, using group as the key and the server group UUID as the value. Using the nova command-line tool, use the --hint flag. For example:

$ nova server-group-create --policy anti-affinity group-1
$ nova boot --image IMAGE_ID --flavor 1 --hint group=SERVER_GROUP_UUID server-1

Schedules the instance based on host IP subnet range. To take advantage of this filter, the requester must specify a range of valid IP address in CIDR format, by passing two scheduler hints:

Using the nova command-line tool, use the --hint flag. For example, to specify the IP subnet 192.168.1.1/24

$ nova boot --image cedef40a-ed67-4d10-800e-17455edce175 --flavor 1 \
  --hint build_near_host_ip=192.168.1.1 --hint cidr=/24 server-1

With the API, use the os:scheduler_hints key:

{
    "server": {
        "name": "server-1",
        "imageRef": "cedef40a-ed67-4d10-800e-17455edce175",
        "flavorRef": "1"
    },
    "os:scheduler_hints": {
        "build_near_host_ip": "192.168.1.1",
        "cidr": "24"
    }
}

Filters hosts based on their trust. Only passes hosts that meet the trust requirements specified in the instance properties.

Dynamically limits hosts to one instance type. An instance can only be launched on a host, if no instance with different instances types are running on it, or if the host has no running instances at all.
